Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Ambient Operating Temperature
0 to 40°C (32 to 104°F)
Brake Coil Current At 24 Vdc
0.69 ADC
Dimensions (mm/in)
213 mm/8.39 in x 266 mm/10.47 in
Encoder Connector Wire Awg
16 (1.5)
Holding Torque
90 lb-in or 10.2 Nm
Max Operating Speed
3000 rpm
Motor Length With Brake (mm/in)
236 mm/9.29 in
Motor Length Without Brake (mm/in)
184 mm/7.24 in
Nema Size
NEMA 56C
Power Connector Wire Awg
12 (4.0)
Thermal Resistance
0.48 °C/Watt
Torque Constant (square Wave)
0.81 Nm/A or 7.2 lb-in/A
Voltage Constant
90 V/krpm
Winding Inductance
5.4 mH
Winding Resistance
0.90 Ohms
