HVE02.2-W018

Original price $13,041.17 - Original price $13,041.17
Original price
$13,041.17
$13,041.17 - $13,041.17
Current price $13,041.17
In Stock, Ships 1 - 2 Days
Request a quote
The HVE02.2-W018, produced by Bosch Rexroth Indramat, is an essential component for operating the drive controller within the drive system. This device supplies control voltage to all connected controllers and provides control voltage via its DC bus voltage during power outages. It comes with monitoring functions communicating with drive controllers through the control voltage bus. Primarily used with 60 kW motors, the HVE02.2-W018 can work in generator mode, dissipating the regenerated energy as heat through a bleeder resistor. A compatible accessory is the CD bus choke GLD. With an IP 10 protection class, it must be situated in a control cabinet with sufficient cooling arrangements to avert a temperature rise beyond 45 degrees. It operates at 5 to 45 degrees and withstands storage and transport temperatures from -30 to 85 degrees. The input voltage, frequency, and maximum power load are 3 x 380 to 480 V, 50/60 Hz, and 500 VA respectively. To control and monitor motors, additional sensors and actors are required. It converts 3-phase AC voltage into unregulated DC bus voltage for linked drive controllers.
30 Day Warranty
Technical Specifications
  • Product Manufacturer: Bosch Rexroth Indramat
  • Product Model: HVE02.2-W018
  • Usage: Operate drive controller in a drive system
  • Control Voltage Supply: Provides control voltage for all connected controllers
  • Functionality: Monitors drive system via control bus voltage
  • Compatible Motor Power: 60 kW mechanical power
  • Generator Mode: Regenerated energy dissipated as heat via a bleeder resistor
  • Optional Combination: CD bus choke GLD
  • Protection Class: IP 10
  • Requiremnts: Control cabinet mounting, air cooling system
  • Operating Temperature: 5 to 45 degrees
  • Storage and Transport Temperature: -30 to 85 degrees
  • Relative Humidity: 95%
  • Installation Altitude: 1000 meters
  • Input Voltage: 3 x 380 … 480 V
  • Frequency: 50/60 Hz
  • Power Input: Maximum 500 VA
  • Optimum Usage Environment: Ambient conditions, not underwater or in extreme temperature
  • Specific Usage: Supply electricity to HDS and HDD drive controllers
  • Accessories: Additional sensors and actors needed to control and monitor motors
  • Method of Operation: Rectifies 3-phase AC voltage into an unregulated DC bus voltage
  • Available from: Servo Supplier
