S image of HVE04.2-W075N/S202

HVE04.2-W075N/S202

by Bosch Rexroth Indramat
$0.00 - $0.00
Request a Quote
$0.00 - $0.00
Request a Quote

Request a quote

Add a Message
The HVE04.2-W075N/S202 power supply, produced by Bosch Rexroth Indramat, boasts a nominal power of 75 kilowatts. Constructed for unregulated DC bus voltage functions, this product from the HVE series can withstand variances in output power linked to changes in input voltage. Optimally, the input voltage for this device ranges from 380 to 480 Volts AC. It has the capacity to sustain 200% of its rated power for 30 seconds, and 300% for as brief as 0.3 seconds, while managing a continuous output power for durations greater than 120 seconds. Encased in an IP 10 rated shell, it has dimensions of 498 x 250 x 262 millimeters and weighs 61.7 pounds. The device should be housed in an industrial cabinet to shield it from dust and moisture. The power supply can separate drive controllers from the mains supply via an internal contactor. Ideal environmental conditions for its operation is a temperature between 41 to 113 degrees Fahrenheit and relative humidity of no more than 95%.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Bosch Rexroth Indramat

Product Model

HVE04.2-W075N/S202

Product Type

Power Supply

Power Rating

75 kW

Product Family

HVE Series

Nominal Input Voltage Range

380 to 480 Volts AC

Peak Power

200% of rated power for up to 30 seconds, 300% of rated power upto 0.3 seconds

Continuous Output Power Duration

More than 120 seconds

Weight

61.7 pounds

Housing Measurement


498 x 250 x 262 millimeters

Housing Rating

IP 10

Input

Three-phase

Features

Alphanumeric Display, Integrated capacitors, Internal contactor, Internal blower

Optimal Temperature for Operation

41 to 113 degrees Fahrenheit

Optimal Humidity for Operation

Up to 95% relative humidity.
