series image of a ICD10030A1P1

ICD10030A1P1

by Kollmorgen
$3,000.00 - $3,000.00
$3,000.00
$3,000.00 - $3,000.00
$3,000.00
Available, Shipping Varies
The ICD10030A1P1, manufactured by Kollmorgen, is a highly efficient, direct drive linear motor with a low profile. Belonging to the ten series of DDL motors, it boasts a 30mm magnetic way width, a Y winding code type, and a 400mm termination option. This motor impresses with a peak force of 330N and a continuous force of 104N. Its mechanical features include an MCD030 magnetic way type, a maximum weight of 1.1 kg, and a magnetic attraction of 1.06kN. The motor, requiring only a 0.031 inches airgap, showcases an efficiency via its low thermal loss, low profile, and high force density. The adoption of fewer components permits a low-maintenance solution and eases integration into applications. Able to be cooled via water or supplemental air cooling methods, it is applicable in various sectors, from flight simulations to water slicing.
30 Day Warranty
Technical Specifications
  • Manufacturer: Kollmorgen
  • Product Type: Direct Drive Linear Motor
  • Model Number: ICD10030A1P1
  • Series: ICD DDL Ten Series
  • Termination Option: 400mm
  • Peak Force: 330N
  • Continuous Force: 104N
  • Maximum Weight: 1.1kg
  • Magnetic Way Type: MCD030
  • Magnetic Way Weight: 2.70kg/m
  • Magnetic Attraction: 1.06kN
  • Electrical Time Constant: 2.9ms
  • Thermal Resistance: 2.05 C/Watt
  • Applications: Flight Simulations, Acceleration Sleds, Wire Bonding, Textile, Semiconductor, Water Slicing
  • Airgap for Frameless Motor: 0.031 inches
  • Cooling: Water or Supplemental Air Cooling
