Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Counting frequency
100 kHz
Current consumption
25 mA
EMC compliance
EN 61000‑6‑2 / EN 61000‑6‑4
Input connector
M12 screw-type
Logic high-level signal voltage
11…30 V (EN 61131‑2 type 2)
Logic low-level signal voltage
-3…+5 V (EN 61131‑2 type 2)
Nominal input voltage
24 V DC (–15% / +20%)
Number of counters
2 (32‑bit depth each)
Number of inputs
2 counter + 2 gate + 2 up/down
Number of outputs
2×24 V DC, 0.5 A, short-circuit-proof
Operating temperature
0…+55 °C
Power supply input connector
1×M8 4‑pin male, A‑coded
Power supply output connector
1×M8 4‑pin female, A‑coded
Process image data width
2×32‑bit data, 2×8‑bit control/status
Process image I/O
80 bits
Sensor supply
From control voltage, max 0.5 A, short-circuit-proof
Storage temperature
–25…+85 °C
Switching frequency (up/down)
2 kHz
Vibration/shock resistance
EN 60068‑2‑6 / EN 60068‑2‑27
