The Beckhoff IE2022-0000 is an extension box unit in the IE Extension Box Units series by Beckhoff, featuring 8 short-circuit proof outputs each delivering up to 2 A at 24 V DC (–15%/+20%). It offers robust M12 screw-type connections, a total current of 4 A and IP65/66/67 protection.
Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Auxiliary Power Current
30 mA per channel
Current Consumption (Us)
25 mA
Downstream Connection
1×M8 female, 4-pin, A-coded
Feed Connection
1×M8 male, 4-pin, A-coded
Installation Position
Variable
Load Types
Ohmic, inductive, lamp
Max. Output Current per Channel
2 A
Nominal Output Voltage
24 V DC (-15%/+20%)
Number of Outputs
8
Operating Temperature
0…55°C
Output Connections
M12, screw type
Protection Rating
IP65/IP66/IP67
Shock Resistance
EN 60068-2-27
Short-Circuit Proof
Individually short-circuit proof
Storage Temperature
-25…+85°C
Total Max. Output Current
4 A
Vibration Resistance
EN 60068-2-6
