S image of IE3202-0000

IE3202-0000

by Beckhoff
$893.72 - $1,883.48
$893.72
$893.72 - $1,883.48
$893.72

In Stock, Ships Fast

The Beckhoff IE3202-0000 from the IE Extension Box Units series is an extension box offering 4 inputs, supporting Pt100/200/500/1000; Ni100/120/1000 and potentiometers. It features a measuring range of −250…+850 °C for Pt sensors and −60…+250 °C for Ni sensors with a 0.1 °C per digit resolution and measurement uncertainty of ±1 °C. The module uses an M12 screw connection for 2-, 3- or 4-wire sensors, a configurable conversion time (≤250 ms down to 65 ms), and operates on a nominal 24 V DC supply (−15%/+20%). With IP65/66/67 protection, electrical isolation of channels at 500 V, and a compact polyamide housing measuring 30×126×26.5 mm, it ensures reliable performance in demanding industrial automation environments.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Connection method

M12 screw for 2-,3-,4-wire (preset 4‑wire)

Conversion time

≈250 ms (configurable to 65 ms)

Current consumption (without sensors)

40 mA

Input filter

5 configurable variants

Measurement uncertainty

<±1 °C

Measuring current

typ. 0.5 mA

Measuring range (Ni sensors)

−60…+250 °C

Measuring range (Pt sensors)

−250…+850 °C

Number of inputs

4

Operating temperature

0…+55 °C

Power downstream connection

1×M8 female, 4‑pin, A‑coded

Power feed connection

1×M8 male, 4‑pin, A‑coded

Process image data width

4×16bit data; 4×8bit control/status optional

Resolution

0.1 °C per digit

Sensor supply

from 24 V control voltage

Storage temperature

−25…+85 °C

Supply voltage

24 V DC (−15%/+20%)

Supported sensor types

Pt100/200/500/1000; Ni100/120/1000; potentiometers
