S image of IE5009

IE5009

by Beckhoff
$0.00 - $0.00
Request a Quote
$0.00 - $0.00
Request a Quote

Request a quote

Add a Message
The IE5009 extension box unit from Beckhoff is part of the IE Extension Box Units series. It features a 12-pin outer thread M23 connector for SSI encoders, supports a nominal voltage of 24 V DC, delivers data transfer rates up to 1 MHz, and uses RS-485 differential signaling for reliable communication. Designed for industrial automation, it offers protection ratings of IP65/66/67 and operates between 0 °C and 55 °C. It consumes just 55 mA and includes a single channel for encoder connections.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Current consumption (without sensor)

55 mA

Data direction

read

Data transfer rate default

250 kHz

Data transfer rate max

1 MHz

Encoder supply voltage

24 V DC (from load)

Nominal voltage

24 V DC (-15%/+20%)

Number of channels

1

Operating temperature

0…55°C

Power downstream connector

M8 female, 4-pin, A-coded

Power feed connector

M8 male, 4-pin, A-coded

Process image control/status width

8 bit (optional)

Process image data width

32 bit

Protection rating

IP65/66/67 (EN 60529)

Serial input resolution

24 bit (adjustable)

Signal input type

RS-485 differential

SSI encoder connector

M23, 12-pin outer thread

Storage temperature

-25…+85°C
