IES-060-30

The Copley Controls IES-060-30 single-board servo drive from the Bantam M-Axis Controllers series by Copley Controls delivers a robust solution for embedded motion control in compact form factors. It supports a voltage range of 14 to 60 Vdc with a peak current of 30 Adc and a continuous current rating of 15 Adc for demanding dynamic loads. The unit operates across control modes including Cyclic Synchronous Position (CSP), Velocity (CSV), and Torque (CST) to suit diverse application profiles. Precision feedback is provided via dual interfaces, BiSS-C and SSI, ensuring accurate position referencing and closed-loop stability. Its dimensions of 80 x 80 x 20 mm combined with a central cutout streamline cable routing and mechanical integration into motor housings and robotic joints. The drive’s lightweight construction and filleted-corner design optimize space utilization in tightly constrained industrial automation assemblies.

Performance is underpinned by a current loop update rate of 16 kHz and a current sense resolution of 12 bits, delivering fine-grained control over motor torque. Position and velocity loops update at 4 kHz (250 μs), enabling fast response to motion commands and high bandwidth trajectory execution. The integrated MOSFET 3-phase inverter uses a 16 kHz center-weighted PWM carrier for smooth commutation and minimal torque ripple. Connectivity includes a CANopen application protocol over EtherCAT (CoE) command interface alongside a full-duplex serial port supporting ASCII or binary protocols. An EtherCAT port provides 100BASE-TX Ethernet speeds with internal magnetic isolation rated to 32 Vdc, while a dedicated MOTEMP input coupled with a programmable 12-bit A/D converter monitors motor temperature for fault detection. With a peak time of 1 second and support for a minimum load inductance of 100 μH, the drive maintains stable control under rapid load transients.

Engineered for reliability in industrial environments, the IES-060-30 incorporates integrated high-voltage compensation to maintain consistent performance across supply variations. Its robust square form factor with filleted corners and a 10 mm cable pass-through simplifies mounting and wiring in confined assemblies. The combination of EtherCAT connectivity and CANopen over EtherCAT supports seamless network integration and real-time coordination in multi-axis systems. This versatile servo drive is ideally suited for precision robotics, automated assembly, and other industrial automation applications requiring high-speed, high-accuracy motor control in a compact footprint.
