IL03030A1104
by Kollmorgen
The Kollmorgen IL03030A1104 motor is a precision motion control solution from the IL Ironless DDL Motors series by Kollmorgen. Featuring a peak force of 120N and a continuous force @ Tmax (1) of 30.3N, it delivers high dynamic response in applications requiring rapid acceleration and deceleration. With a peak current rating of 7.1lp, this ironless motor is designed for seamless integration into systems demanding smooth, cog-free operation and precise positioning. Its primary function is to provide high force density in automated machinery, robotics, and semiconductor handling.
Incorporating a magnetic way type of MW030, the IL03030A1104 employs a 3-phase sinusoidal commutation scheme to ensure zero cogging and negligible attractive force. The stator coil assembly exhibits an electrical inductance ±20% of 1.3mH L-L, enabling rapid current changes for fast transient response. Thermal management is optimized by a thermal resistance of 1.61°C/Watt, allowing continuous operation up to the maximum coil temperature without performance degradation. The motor’s low mass coil assembly (0.27 kg ±15%) further enhances its acceleration capability, delivering over 10 G in transient loads with minimal settling time.
This ironless design eliminates iron losses and friction, resulting in ultra-efficient operation and minimal maintenance requirements. The brushless, contactless construction means no wear components, ensuring extreme longevity and consistent performance under continuous duty cycles. Compatibility with precision feedback devices and modular magnetic components allows straightforward integration into diverse industrial control architectures. While no specific certifications are listed, the robust thermal and electrical characteristics support reliable operation in demanding environments. By combining high force density, zero cogging, and rapid thermal dissipation, the IL03030A1104 boosts throughput, reduces cycle times, and enhances positional accuracy for advanced automation systems.
