S image of IL12030A1TRP1

IL12030A1TRP1

by Kollmorgen
$1,506.95 - $1,506.95
$1,506.95
$1,506.95 - $1,506.95
$1,506.95

In Stock, Ships 1 - 3 Days

The IL12030A1TRP1 is a high-quality product from Kollmorgen, renowned for manufacturing durable, innovative, and technologically advanced motion control components. The product boosts efficiency and cost-effectiveness in complex applications, with its design ensuring ease of installation. It is part of a range that includes CNC, gearing, servo motors, drive controllers, power cables, mains filters, spindle drives, and supply modules. Specifically, this ironless non-cooled motor series boasts a zero magnetic attraction, 0.8040/watt thermal resistance, and permits a maximum coil temperature of 1300. Weighing at approximately 0.42 kgs, it supports a continuous current between 1.8 to 7.4 A and a peak current range from 7.1 to 28.5 Amps. Its peak force and continuous force stand at 240N and 66.2N respectively. Additionally, it maintains an electrical resistance of 0.8 to 12.2 Ohms at 250C, a 7.8 N/W motor constant, a back EMF constant between 0.17 to 0.70 Vpeak/in/sec, a maximum theoretical acceleration of 58.2 g’s, and an electric time constant of 0.21 m/s.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Kollmorgen

Product Model

IL12050A1TRP1

Product Type

Ironless Non-cooled Motor Series

Magnetic Attraction

0

Thermal Resistance

0.8040/watt

Maximum Allowable Coil Temperature

1300C

Coil Assembly Net Weight

0.42 kgs (+/- 15%)

Continuous Current

1.8 to 7.4 A

Peak Current

7.1 to 28.5 Amps

Peak Force

240 N

Continuous Force

66.2 N

Electrical Resistance at 250C

0.8 to 12.2 Ohms (+/- 10%)

Motor Constant

7.8 N/W

Back EMF Constant

0.17 to 0.70 Vpeak/in/sec (+/- 10%)

Maximum Theoretical Acceleration

58.2 g

Electric Time Constant

0.21 m/s
