S image of IL18030A1TRC4

IL18030A1TRC4

by Kollmorgen
$671.83 - $671.83
$671.83
$671.83 - $671.83
$671.83

In Stock, Ships 1 - 3 Days

Produced by Kollmorgen, a renowned manufacturer well-versed in crafting industrial automation products, the IL18030A1TRC4 is part of their ironless, non-cooled motor series. With an unerring commitment to addressing challenges with cost-effective, efficient solutions, Kollmorgen ensures quality across their range of products which includes drive controllers, motors, CNC, gearing, and power cables among others. The IL18030A1TRC4 motor showcases a consistent force of 92.1 N, a peak force of 360 N, and a motor constant at 250C of 9.7 N/W. The model offers maximum theoretical acceleration of 64.5 g's and an electric time constant of around 0.21 m/s. Aside from presenting zero magnetic attraction, the unit touts a thermal resistance of 0.5360/watt and accommodates a maximum coil temperature of 1300. With a coil assembly weight of approximately 0.32 kgs, electric specifications range from a peak current of 7.1 to 42.8 Amps and a continuous current of 1.8 to 11.0 A.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Kollmorgen

Product Code

IL18030A1TRC4

Motor Type

Ironless Non-Cooled

Continuous Force

92.1 N

Peak Force

360 N

Motor Constant @ 250C

9.7 N/W

Maximum Theoretical Acceleration

64.5 gs

Electric Time Constant

0.21 ms

Magnetic Attraction

0

Thermal Resistance (Coils to External Structure)

0.5360/watt

Max Allowable Coil Temperature

1300

Coil Assembly Weight

0.32 kgs +/- 15%

Peak Current Range

7.1-42.8 Amps

Continuous Current

1.8-11.0 A

Electric Inductance +/- 20%

0.11 to 3.8 mH

Electric Resistance @ 250 +/- 10%

0.5 to 18.2 Ohms

Magnetic Way Type

MW
