IL18100A3TRC4

Original price $4,387.41 - Original price $4,387.41
Original price
$4,387.41
$4,387.41 - $4,387.41
Current price $4,387.41

In Stock, Ships Fast

The IL18100A3TRC4, a product of Kollmorgen, is a brushless direct-drive linear servomotor. It belongs to the IL18 series and features an ironless design with a modular magnet way. The motor is designed with two rows of magnets placed in opposition to each other, ensuring an effective flux return path in the magnetic circuit. This servomotor is renowned for its high positional accuracy and smooth velocity. With a 21.3ARMS peak current and 0.29°C/W thermal resistance, it easily meets diverse payload and stroke needs. It utilizes Hall Effect feedback for sinusoidal commutation and a flat rotor that doubles as a magnet track. This servomotor is suitable for applications demanding minimal thermal loss and low settling time, along with high acceleration and stiffness. Its compact design and low-maintenance operation, along with a 2.4 +/-15%kg coil assembly weight, make it an ideal fit for space-constrained use.

Contact Us

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer


Kollmorgen

Product Code


IL18100A3TRC4

Motor Type


Brushless Direct-Drive Linear

Phase


Three-Phase Servomotor

Design


Ironless Unit with Modular Magnet Way

Positional Accuracy


High

Velocity


Very Smooth

Peak Current


21.3ARMS

Thermal Resistance


0.29°C/W

Feedback Type


Hall Effect for Sinusoidal Commutation

Rotor Type


Flat

Thrust Force


High

Magnet Track


Light Mass

Cogging Attractive Force


Zero

Thermal Loss


Very Low

Settling Time


Low

Connector


Two-Pin Male

Thermal Protection Terminals


Two Female

Weight of Coil Assembly


2.4 +/-15%kg

Lubrication


Not Required

Component Inclusion


Does not include screws or gears

Delivery


Worldwide Shipping.
