The Beckhoff IL2301-B905-0000 is a coupler box from the IL Coupler Box Units series. Offering 4 inputs and 4 outputs with M8 screw type connectors, it supports 24 V DC load voltage and a short-circuit-proof sensor supply up to 0.5 A. Meeting EN 61000-6-2/6-4 EMC standards with IP65 protection, it operates from 0 to 55 °C.
Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Auxiliary power current
typ. 20 mA
Connections
M8, screw type
EMC immunity/emission
EN 61000-6-2 / EN 61000-6-4
Input filter time
3.0 ms
Input signal voltage (type 0)
-3…+5 V
Input signal voltage (type 1)
11…30 V, 6 mA input current
Load types
ohmic, inductive, lamp
Max. output current
0.5 A/channel, short-circuit proof
Number of inputs
4
Number of outputs
4
Operating temperature range
0…+55°C
Rated load voltage
24 V DC (-15%/+20%)
Sensor supply current
max. 0.5 A from control voltage, short-circuit proof
Shock resistance
EN 60068-2-27
Short-circuit current
typ. 1.5 A
Storage temperature range
-25…+85°C
Vibration resistance
EN 60068-2-6
