IL24100A3TRC4

Original price $0.00 - Original price $0.00
Original price
Request a Quote
$0.00 - $0.00
Current price Request a Quote

Request a quote

Add a Message
The IL24100A3TRC4, a direct-drive linear motor, is a product of Kollmorgen. This ironless motor is characterized by its silent operation and need for zero maintenance, thanks to its minimal partdesign which also enhances the reliability of the machine. Its key features include a maximum continuous force of 262 N, a peak force of 1600 N and a complete absence of attractive force and cogging. The three-phase, brushless servo motor encompasses a flat rotor but does not entail motor mounts, nuts, couplings, or bearing blocks. It utilizes a Hall Effect device for feedback and boasts an A3 winding code, 4.6 ARMS continuous current and a back EMF constant of 46.6 +/- 10% Vpeak/m/s L-L at 25°C. Designed for varied applications like wafer slicing, wire and tab bonding, and more, the IL24100A3TRC4 includes high stiffness, smooth velocity, and high positional accuracy.

Contact Us

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer


Kollmorgen

Product Code


IL24100A3TRC4

Motor Type


Direct-Drive Linear

Series


IL24

Maximum Continuous Force


262 N

Peak Force


1600 N

Force Constant


57.0 N/ARMS

Winding Code


A3

Continuous Current


4.6 ARMS

Peak Current


28.1 ARMS

Back EMF Constant


46.6 +/- 10% Vpeak/m/s L-L at 25° C

Acceleration


115 gs Maximum Theoretical

Magnetic Way Type


MW100

Lead Length


1200 mm

Connector Shell Size


2

Air Gap


1.12 inches

Overall Length


398.8 mm

Coil Assembly Weight


1.42 +/-15% kg

Feedback


Hall Effect Device

Mounting Holes


3 holes, 0.25 inches diameter each
