The KA511XXX from Sanyo Denki features a 54 mm motor flange size and a rated output of 0.11 kW. Part of the K SANMOTION Servo Motors series, this servo motor operates at a rated speed of 3000 min⁻¹ and carries an IP43 protection rating.
It delivers a continuous stall torque of 0.42 Nm and a peak stall torque of 3.4 Nm with a rotor inertia of 0.37×10⁻⁴ kg·m². The unit uses a Lead wire connection and has no oil seal.
Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Connection
Lead wire
Continuous Stall Torque [n·m]
0.42
Maximum Speed [min⁻¹]
5000
Motor Flange Size [mm]
54
Oil Seal
No
Output Shaft
With key
Peak Stall Torque [n·m]
3.4
Protection Rating
IP43
Rated Armature Voltage [v]
75
Rated Output [kw]
0.11
Rated Speed [min⁻¹]
3000
Rotor Inertia [×10⁻⁴ Kg·m²]
0.37
Servo Motor Mass [kg]
0.9
Tachometer Generator
No
