The KBM-35H01-020 from Kollmorgen weighs 1.23 kg and has an outer diameter of 95 mm. Part of the KBM Brushless Motors series, it delivers a continuous torque of 2.24 Nm and a peak torque of 10.7 Nm.
It operates at a rated speed of 2500 rpm and reaches a maximum speed of 7800 rpm while drawing 4.2 A. The motor features a torque constant of 0.539 Nm/A and supports efficient operation up to 155 °C.
Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Continuous Current Rms @ 75°c
4.2 A
Continuous Power @ 75°c
590 W
Continuous Torque @ 75°c
2.24 Nm
Inductance (line-to-line)
12.5 mH
Max Speed
7800 rpm
Outer Diameter
95 mm
Peak Current Rms
12.1 A
Peak Torque
10.7 Nm
Rated Speed
2500 rpm
Resistance (line-to-line, 25°c)
2.66 Ohms
Rotor Inner Bore Diameter
2.5595 inches
Stator Height
20 mm
Torque Constant (kt)
0.539 Nm/A
Voltage Constant (ke)
56 V/krpm
Weight (stator + Rotor)
1.23 kg
