The KL2284 is a digital output terminal manufactured by Beckhoff in the KL Analog Input Modules series, offering four H-bridge channels with a nominal voltage of 0-24 V AC/DC and a max. output current of 2 A per channel. It withstands peak currents of 5 A (100 ms), has a breakdown voltage of 80 V, and operates between 0-55°C.
Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Bit Width In The Process Image
8 outputs
Breakdown Voltage
80 V
Connection Technology
2-wire
Current Consumption K-bus
100 mA
Max. Output Current
2 A per channel
Nominal Voltage
0…24 V AC/DC
Number Of Outputs
4 x H-bridge circuit
On-resistance
typ. 0.03 Ω
Operating Temperature
0…55°C
Peak Current
5 A (100 ms), < 50 A (10 ms)
Storage Temperature
-25…+85°C
Switching Off Speed
typ. 30 ms, max. 50 ms
Switching On Speed
typ. 235 ms, max. 300 ms
Vibration/shock Resistance
conforms to EN 60068-2-6/EN 60068-2-27
