KL2602
by Beckhoff
{"paragraphs":["
The KL2602 from Beckhoff features two make contacts and supports 230 V AC/30 V DC operation. Part of the KL Analog Input Modules series, it delivers 5 A per channel and switches ohmic, inductive, and lamp loads. It accepts a minimum load of 10 mA at 5 V DC and handles inductive currents up to 2 A AC/DC.
","A lamp test drives up to four 58 W lamps with a 5 A starting current via its built-in power relay. It draws 80 mA from the K-bus. The module weighs just 85 g for easy panel integration.
"]}
