KL2809-0000

The Beckhoff KL2809-0000 digital output terminal from the KL Analog Input Modules series delivers robust industrial digital switching capabilities for demanding automation tasks. Designed and manufactured by Beckhoff, this module provides 16 outputs with an output current per channel of 0.5 A, enabling precise control of ohmic, inductive, and lamp loads. Mountable on a standard 35 mm DIN rail, the KL2809-0000 features reverse voltage protection and short-circuit proof outputs, ensuring reliable operation in harsh factory environments. With EMC immunity certified to EN 61000-6-2 and emission compliance to EN 61000-6-4, this terminal offers stable performance amidst electrical disturbances. The compact design weighs only approx. 70 g and optimizes cabinet space without sacrificing functionality.

Detailed technical specifications define the module’s operational envelope: it operates on a nominal voltage of 24 V DC (-15%/+20%) and supports a current consumption on the K-bus of typ. 35 mA plus load current on the power contacts. The connection technology is a streamlined 1-wire design for simplified wiring and reduced installation complexity. Each channel is protected by a breaking energy rating of < 150 mJ/channel and limited to a short-circuit current of < 2 A, safeguarding downstream devices. The process image accommodates 16 output bits for real-time data exchange. Environmental tolerances extend from -25 … +60 °C in operation and -40 … +85 °C in storage, with vibration and shock resistance conforming to EN 60068-2-6 and EN 60068-2-27.

Operational features of the KL2809-0000 emphasize ease of integration and high reliability. The module’s short-circuit proof outputs and reverse voltage protection eliminate the need for external fuses or polarity guards. At startup, a typical 35 mA current consumption on both the K-bus and power contacts secures fast device initialization. The digital outputs handle a variety of load types, including inductive, resistive, and lamp loads, providing versatile application coverage. Its lightweight construction and compact 70 g weight simplify handling and installation, while the 35 mm DIN rail mounting ensures secure positioning and rapid replacement.

System integration is facilitated by seamless compatibility with Beckhoff’s industrial I/O architecture and EtherCAT® networks, enabling synchronized control across complex automation systems. The KL2809-0000’s digital outputs can be configured and monitored via standard Beckhoff configuration tools, accelerating commissioning processes. Target applications include material handling, conveyor systems, packaging machinery, and general machine automation where reliable switching of multiple loads is essential. The robust electrical protection and wide operating temperature range make this module particularly suitable for harsh manufacturing environments and continuous operation.
