The Beckhoff KL5101-0000 is an incremental encoder interface in the KL Analog Input Modules series. It offers 1 encoder channel with a 16-bit counter and RS422 differential inputs (A, A (inv), B, B (inv), C, C (inv)), supports quadrature decoding up to 4× evaluation at 4,000,000 increments/s, and features a 24 V DC power supply with typical 60 mA consumption.
Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Channels
1 encoder + 1 input
Counter
16 bit binary
Encoder inputs
A, A inv, B, B inv, C, C inv (RS422 diff)
Encoder operating voltage
5 V DC
Encoder output current
0.5 A
Gate/latch input voltage
24 V DC
K-bus current consumption
typ. 60 mA
Limit frequency
4,000,000 increments/s (4× eval)
Operating temperature
-25 to +60°C
Power supply
24 V DC (-15%/+20%)
Process image control width
8 bit
Process image data width
16 bit
Quadrature decoding
1×, 2×, 4× evaluation
Status input voltage
5 V DC
Storage temperature
-40 to +85°C
Supported commands
read, set, enable
Vibration/shock resistance
EN 60068-2-6/-2-27
Weight
approx. 85 g
Zero-pulse latch
16 bit
