S image of KM2004-0000

KM2004-0000

by Beckhoff
$637.81 - $637.81
$637.81
$637.81 - $637.81
$637.81

In Stock, Ships Fast

The KM2004-0000 bus terminal from Beckhoff is part of the KM Bus Terminals series. It provides 32 outputs with 24 V DC nominal voltage, a short-circuit proof max current of 0.5 A per channel, and breaking energy under 150 mJ. The terminal features reverse voltage protection and meets EMC standards EN 61000-6-2/-6-4. It complies with shock resistance (EN 60068-2-27) and vibration resistance (EN 60068-2-6) standards.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Breaking energy

< 150 mJ/channel

Connection technology

Plug

EMC immunity/emission

EN 61000‑6‑2 / EN 61000‑6‑4

K‑bus current consumption

typ. 5 mA

Load types

Ohmic, inductive, lamp

Max output current

0.5 A per channel (short‑circuit proof)

Nominal voltage

24 V DC (‑15%/+20%)

Number of outputs

32 (4 x 8)

Operating temperature

0…+55 °C

Power contacts current consumption

None (no power contacts)

Process image bit width

32 outputs

Reverse voltage protection

Yes

Shock resistance

EN 60068‑2‑27

Short‑circuit current

< 2 A

Storage temperature

‑25…+85 °C

Vibration resistance

EN 60068‑2‑6

Weight (1‑pin connector)

approx. 90 g

Weight (3‑pin connector)

approx. 110 g
