KM2008

The Beckhoff KM2008 is a robust member of the KM Bus Terminals series designed for demanding industrial automation environments. Manufactured by Beckhoff, this bus terminal module supports up to 64 digital output channels configured across eight connectors, ensuring versatile signal distribution. The module operates on a nominal voltage of 24 Volts DC with a tolerance of –15%/+20% and delivers reliable performance within an operating temperature range of 0 °C to 55 °C. With a protection rating of IP20 and a compact footprint of 123 × 100 × 55 mm, the KM2008 balances durability with space efficiency. Its lightweight construction—310 g with single-pin connectors and 390 g with three-pin connectors—facilitates easy handling and installation.

Equipped with spring connection technology and plug connection technology, the KM2008 ensures rapid, tool-free field wiring and accommodates cable cross-sections from 0.08 to 1.5 mm² with an 8 mm stripping length. Each output channel is short-circuit proof and features reverse voltage protection, with a maximum short-circuit current of less than 2 Amps and a breaking energy of under 150 mJ per channel. The module provides 500 Volts of electrical isolation between the K-bus and the field potential, minimizing interference and enhancing signal integrity. Its output channels support lamp, inductive, and resistive loads, delivering up to 0.5 A per channel and sustaining at least 50,000 switching cycles of electrical life. Nominal bit width of 64 outputs in the process image facilitates high-density data mapping to higher-level controllers.

Operational reliability is reinforced by a rated voltage of 250 V AC on its push-button switch interface and a mounting hole diameter of 16 mm that aligns with standard panel cutouts. The KM2008 features a single NO contact configuration on its switch, providing straightforward manual control when needed. Ambient conditions supported include storage from –25 °C to +85 °C and up to 95% relative humidity, ensuring stable performance in fluctuating environments. Installation on a 35 mm DIN rail compliant with EN 60715 offers flexibility in system layout and quick module replacement without disrupting adjacent modules.

Seamless integration into Beckhoff’s K-bus infrastructure enables straightforward expansion of digital output capabilities in machine automation, process control, and building management systems. The module’s compact dimensions and DIN-rail mounting simplify retrofits and new installations alike, while IP20 protection ensures safe operation in controlled indoor conditions. Whether deployed in packaging machinery, conveyor systems, or distributed I/O architectures, the KM2008 delivers precise, high-integrity switching performance. Its compliance with Beckhoff’s automation ecosystem guarantees compatibility with EtherCAT controllers, TwinCAT software, and a wide array of complementary I/O modules, enabling scalable solutions for diverse industrial applications.
