KT1-PDT-B23-20

The Sanyo Denki KT1-PDT-B23-20 is a precision-engineered operator interface component within the PDT San Driver Servo Drives series, designed to harmonize human-machine interaction with industrial automation systems. This pushbutton switch features a Momentary actuator style and a robust Double Throw (DPDT) contact type to accommodate complex control schemes. The switch carries a Contact Rating of 10A at 250VAC, ensuring reliable current handling even under heavy operational loads. Integrated LED illumination at 24V provides clear visual feedback of switch status in low-light environments. Its Panel Mount configuration and compact Panel Cutout Diameter of 22mm facilitate direct integration into control panels without sacrificing valuable cabinet real estate.

Equipped for demanding industrial environments, the KT1-PDT-B23-20 delivers consistent performance across a wide Operating Temperature Range of –20°C to +55°C, minimizing derating or failure in temperature extremes. The Screw Terminal connections ensure secure, low-resistance electrical contact while simplifying field wiring and maintenance tasks. An Ingress Protection rating of IP65 safeguards internal contacts against dust ingress and water jets, preserving switch integrity and extending service life. The DPDT arrangement supports versatile circuit configurations, enabling users to implement both normally open and normally closed contact paths. As a precision input device, it responds instantaneously to operator commands, with minimal contact bounce and mechanical lag. Designed for reliable duty, the switch’s mechanical travel and tactile feedback are optimized to maintain consistent actuation force over more than 100,000 cycles.

Engineered for seamless integration, the KT1-PDT-B23-20 aligns with standard industrial panel layouts and control architectures, reducing installation time and engineering effort. Its resilient construction and IP65 sealing ensure dependable operation in harsh production environments—ranging from metalworking to food and beverage processing. The switch’s Momentary action and DPDT configuration make it ideal for start/stop controls, mode selection, and emergency override functions in factory automation. Low-profile design and standardized 22mm cutout compatibility allow retrofit into existing panels without major redesign. Overall, the KT1-PDT-B23-20 offers the reliability, technical versatility, and professional appearance that OEMs and system integrators require for advanced industrial control applications.
