S image of LSM100-46-454-M-0KA

LSM100-46-454-M-0KA

by Kollmorgen
$5,157.85 - $5,157.85
$5,157.85
$5,157.85 - $5,157.85
$5,157.85

Available, Shipping Varies

The Kollmorgen LSM100-46-454-M-0KA from the LSM Brushless Servo Motors series by Kollmorgen is a high-performance brushless servo motor delivering a continuous torque of 5.2 Nm and a peak torque of 16 Nm at up to 4500 rpm. With an inertia of 0.00017 kg·m², it ensures rapid dynamic response, supported by a torque constant of 0.88 Nm/A and a back EMF constant of 106 V/kRPM. The motor features 8 winding poles and a phase-to-phase winding resistance of 3.9 Ω at 25 °C, while weighing 6.3 kg for integration into medium-frame industrial automation systems. Rated for a maximum current of 21.2 A and a stall current of 6.4 A, it offers reliable acceleration, braking, and precise motion control across diverse applications.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Continuous Torque (in-lb)

46

Continuous Torque (nm)

5.2

Ke Voltage Constant (v/krpm)

106

Kt (nm/amp)

0.88

Maximum Current (amps Peak)

21.2

Motor Net Weight (kg)

6.3

Motor Net Weight (lb)

13.9

Peak Torque (in-lb)

142

Peak Torque (nm)

16

Shaft Material

ST-60

Speed (rpm)

4500

Stall Current (amps Peak)

6.4

Winding Inductance Phase To Phase (mh)

12.44

Winding Poles

8

Winding Resistance Phase To Phase @ 25°c (ohm)

3.9
