The Kollmorgen LSM165-173-304-S-0KA is a robust brushless servo motor from the LSM Brushless Servo Motors series, offering a continuous torque of 19.5 Nm and peak torque of 75 Nm at 3000 rpm. Featuring a ST-60 shaft, Ke voltage constant of 156 V/kRPM, maximum current of 72.1 Amps and IP65 protection, it weighs 18.7 kg.
Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Continuous Torque
19.5 Nm (173 In-lb)
Ke Voltage Constant
156 V/kRPM
Kt (torque Constant)
1.29 Nm/Amp
Maximum Current (peak)
72.1 Amps
Motor Net Weight
18.7 kg (41.2 lb)
Motor Net Weight With Brake
21 kg (46.3 lb)
Peak Torque
75 Nm (664 In-lb)
Rotor Moment Of Inertia
0.00128 kg-m² (0.0113 lb-in-s²)
Rotor Moment Of Inertia With Brake
0.00163 kg-m² (0.0144 lb-in-s²)
Shaft End Threaded Hole
M10 x 1.5 mm, Depth 22 mm
Shaft Material
ST-60
Speed
3000 rpm
Stall Current (peak)
16.5 Amps
Winding Inductance Phase-to-phase
9.6 mH
Winding Resistance Phase-to-phase At 25°c
0.98 Ohm
