S image of LSM63-12-602-E1-0KA

LSM63-12-602-E1-0KA

by Kollmorgen
$0.00 - $0.00
Request a Quote
$0.00 - $0.00
Request a Quote

Request a quote

Add a Message

The Kollmorgen LSM63-12-602-E1-0KA motor from the LSM Brushless Servo Motors series by Kollmorgen is a high-reliability brushless servo motor offering a continuous torque of 1.4 Nm and peak torque of 5.6 Nm at a nominal speed of 6000 RPM. With a torque constant of 0.36 Nm/Amp, a voltage constant of 43 V/kRPM, and a rotor moment of inertia of 0.00002 kg-m², it delivers fast acceleration and precise control. The compact design features a motor length of 154 mm and a net weight of 1.8 kg, with a 9 mm steel shaft and integrated encoder. Natural airflow cooling and CE certification ensure maintenance-free operation in industrial automation.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Continuous Torque

1.4 Nm (12 In-lb)

Flange Dimensions

A: 55 mm, B: 40 mm, C: 6 mm, E: 63 mm

Ke Voltage Constant

43 V/kRPM

Kt (torque Constant)

0.36 Nm/Amp

Maximum Current (peak)

15.8 Amps

Motor Length

154 mm from face

Motor Net Weight

1.8 kg (4 lbs)

Peak Torque

5.6 Nm (50 In-lb)

Rotor Moment Of Inertia

0.00002 kg-m² (0.00017 lb-in-s²)

Shaft Dimensions

Diameter: 9 mm, Key Depth: 1.8 mm

Shaft Material

Steel

Speed

6000 RPM

Stall Current (peak)

4.1 Amps

Winding Inductance (phase To Phase)

13 mH

Winding Resistance (phase To Phase At 25°c)

3.68 Ohms
