LSM63-12-604-M-0KA-240N
by Kollmorgen
The LSM63-12-604-M-0KA-240N is a product of Kollmorgen, recognized for its 6,000 rpm LSM brushless motor, primarily fitted in industrial drive machinery. Notable features include inbuilt temperature sensors for intelligent shutdown during overload, a radial load force of 23 kg, continuous torque and peak torque standing at 1.4 Nm and 5.6 Nm respectively, and a 4.1 Amps stall current. Designed without a keyway, its steel shaft weighs 1.8 kg and shows a moment of inertia valuing at 0.00002 kgm2. It utilizes a multiturn, high-resolution feedback mechanism, with a winding resistance of 3.68 at 25oC. The motor's optimal application necessitates belt pulleys and direct mount pinions, alongside benefitting from a unique stator design for optimal heat transfer. Lastly, it leverages high-energy rotors made from neodymium magnets for significant deceleration and acceleration, with its ideal operating temperature falling between 0 – 40oC.
