LSM75-10-602-E2-0KA
by Kollmorgen
The LSM75-10-602-E2-0KA is an advanced brushless servo motor from Kollmorgen, part of the renowned LSM Brushless Servo Motors series. This motor delivers a rated power of 0.42 kW and operates at a speed of 6000 RPM, offering high-efficiency performance in a compact package. The design features a Flange Diameter of 75 mm and a lightweight construction weighing just 3.1 kg (Motor Net Weight), ensuring easy integration into existing systems. With 8 Poles and a voltage constant (Ke) of 49 V/kRPM, the LSM75-10-602-E2-0KA balances torque and speed for demanding industrial applications. Insulation class F and an ambient temperature rating up to 40°C provide the durability required for continuous operation in automation environments.
Offering robust performance, the LSM75-10-602-E2-0KA delivers a Continuous Torque of 2.36 Nm and achieves a Peak Torque of 8.8 Nm at maximum demand. Electrical characteristics include a Winding Resistance Phase-to-phase of 2.26 Ω and a Winding Inductance Phase-to-phase of 17.9 mH, supporting precise current control. The servo motor supports inverter duty operation with a Maximum Current of 21.6 Amps peak and a Stall Current of 5.5 Amps peak, ensuring rapid acceleration and deceleration. A Rotor Moment Of Inertia of 0.000033 kg·m² contributes to responsive dynamic behavior, while the Length Adjustment For Sin/cos Feedback of +25 mm enables fine-tuning of encoder alignment. Operating on 230 Volts at 400 Hz, this motor is optimized for both V/F PWM and VT control methods, delivering smooth, accurate motion profiles.
Engineered for reliability and seamless integration, the LSM75-10-602-E2-0KA features an IP65 protection rating for complete dust and water ingress resistance, meeting stringent industrial standards. Its Steel shaft material and robust flange mounting with threaded holes allow for secure coupling to mechanical assemblies without a keyway. The right-angle heavy-duty industrial power connector simplifies installation and ensures dependable electrical and feedback connections. Length adjustment provisions for sin/cos feedback support precise encoder mounting, making it ideal for applications in robotics, packaging machinery, and CNC systems. Backed by Kollmorgen’s rigorous quality protocols and compliance with EN 60034 and UL standards, this servo motor is a reliable choice for high-performance automation solutions.
