LTE12 0 608 750 001

Request a quote
The LTE12 0 608 750 001 is a servo amplifier from the LTE12 series, made by Bosch Rexroth Indramat. Its primary functions include powering, controlling, and monitoring EC motors. Identified features include a brake chopper for enhanced braking and absorbing voltage peaks, a line filter, intermediate circuit, drive card, and a power supply module. The amplifier is attached to the EC motor via DIP and rotary switches. Operating with a supply voltage of 110-115V, it has a power consumption range of 500VA to 250VA, an output voltage of 310VDC, an output frequency of 0-500Hz, and an output current from 3A to 12A. The amplifier, which falls under protection category IP 40, is recommended for an operating temperature between 0 and 45 degrees Celsius, storage temperature of -20 to 70 degrees Celsius, and should be installed with a 100mm clearance below for plug connection.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product Type: Servo Amplifier
  • Series: LTE12
  • Use: Supply, Control, Monitor EC Motors
  • Component: Brake Chopper
  • System Components: Line Filter, Intermediate Circuit, Drive Card, Power Supply Module
  • Securement: DIP and Rotary Switches
  • Location of Switches: Upper Part of Servo Amplifier
  • Nominal Supply Voltage: 110V to 115V
  • Maximum Power Consumption: 500VA to 250VA
  • Output Voltage: 310VDC
  • Output Frequency: 0 to 500Hz
  • Output Current: 3A to 12A
  • Protection Category: IP 40
  • Operating Temperature: 0 to 45 Degrees
  • Storage Temperature: -20 to 70 Degrees
  • Maximum Operating Altitude: 1000m
  • Clearance Below Unit: 100mm
  • Motor Transducer Cable Length: 3 to 20m
  • Control Cable Length: 0.5m to 10m
  • Monitoring: Temperature and Voltages
  • Additional Features: Integrated Line Filter
  • Mounting Recommendation: Close to Assembly Process
