S image of M.1302.8132

M.1302.8132

by Kollmorgen
$0.00 - $0.00
Request a Quote
$0.00 - $0.00
Request a Quote

Request a quote

Add a Message

The M.1302.8132 from Kollmorgen features a continuous output current of 10 A and a power rating of 2 kW. Part of the MMC Standalone Smart Drives, it supports an input voltage range of 207–528 VAC and delivers a peak output current of 30 A.

It offers optical isolation between logic and field sides, a DC bus capacitance of 1880 µF, and a shunt switch threshold of 780 VDC. The drive also provides 38 J of energy absorption and employs a digital standard width design without BiSS.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

24 V Supply Transient Suppression

Transient suppression on 24 V external supply

Continuous Output Current

10 A

DC Bus Capacitance

1880 μF

Drive Type

Digital standard width, no BiSS

Energy Absorption Capacity

38 J (230 V motor, 230 V line input)

Input Current

14.8 A RMS @460 V AC

Input Frequency

47-63 Hz

Input Voltage

207-528 V AC, 3-phase (400 V nominal)

Logic Circuit Isolation

Optical isolation between logic and field side

Max Inrush Current

4 A for 10 ms

Output Frequency

0-450 Hz

Peak Output Current

30 A

Power Rating

2 kW

Shunt Switch Threshold

780 V DC

Switch Characteristics

Solid-state switches
