M2PSCP35-0
The M2PSCP35-0 clamp plate module from B & R Automation is a robust component within the MCN Power Supply Modules series, designed for industrial automation and control systems. This M2 Power Supply Clamp Plate features a Length 35 mm, Width 12 mm, and a Thickness 2.0 mm profile, enabling compact installation on DIN rails or panels. Constructed from steel with a zinc-plated finish, the module ensures mechanical durability and corrosion resistance in demanding environments. With an operating temperature range of -25°C to +80°C and full RoHS compliance, the M2PSCP35-0 meets stringent industrial and environmental standards.
This power supply module delivers reliable electrical performance with an input rating of 120V AC at 50/60 Hz and provides a regulated 5V DC output at 3.7A, supporting up to 60 W of continuous power. The integrated user-replaceable battery backup safeguards against power interruptions, while the onboard EEPROM Module EE32 stores critical configuration data under all operating conditions. A built-in 250V 2.5A delay-type fuse protects downstream circuitry, and the unit’s Compliance: CE Marked status verifies adherence to international safety and EMC directives. Connectivity is facilitated through a total of 5 front connectors and 2 back connectors, ensuring straightforward wiring and system integration.
Operational reliability is enhanced by a suite of Status Indicators—including BAT OK, DC OK, Ready, AC ON, and STATUS—for real-time monitoring and diagnostics. The module’s IP20 ingress protection rating safeguards against solid particle intrusion, while the Mounting Hole Diameter M2 allows precise fastening and alignment. Designed for humidity ranges from 5% to 95% non-condensing, the M2PSCP35-0 maintains consistent performance in a variety of ambient conditions. The combination of robust construction, comprehensive indicator set, and fault-protection features simplifies maintenance and reduces downtime in critical power distribution applications.
Integration of the M2PSCP35-0 into industrial control panels and automation racks is seamless, thanks to its standardized dimensions and DIN rail compatibility. Engineers can leverage the module’s compact form factor and versatile connector layout for both new installations and retrofitting legacy systems. Its CE Marked certification and RoHS compliance make it suitable for global deployment in manufacturing, process control, and energy distribution networks. Whether used in machine tooling, robotics, or distributed I/O systems, the M2PSCP35-0 ensures dependable power supply performance and simplified system architecture.
