MAC063A-0-ES-4-C/095-A-0/WI520LV
The MAC063A-0-ES-4-C/095-A-0/WI520LV motor from Bosch Rexroth Indramat is part of the MAC AC Servo Motors series, engineered for precision industrial automation. This permanent magnet motor features a standardized Size 063 construction with frame length A and offers a rotor moment of inertia of 2.4 x 10⁻⁴ kg·m², ensuring low inertia and rapid acceleration response. With a nominal speed of 3500 min⁻¹ and a peak pulse current capacity of 12 A, it delivers consistent high-speed performance and dynamic torque handling. The front-panel IP54 sealing provides robust protection against dust ingress and water spray, maintaining operational integrity in harsh environments. Temperatures from 32–140°F (0–60°C) are supported by the motor’s materials and natural convection cooling, which dissipates heat effectively without auxiliary fans.
The MAC063A-0-ES-4-C/095-A-0/WI520LV excels under varying load profiles, tolerating overloads of 1.2× continuous and AC current 20× for 1 second for brief high-demand cycles. Its electrical stability is characterized by an Ac Rms Meters Influence of 30% 3rd harmonic influence <1.5% and a Temperature Influence of 0.033% °F typical (0.06% °C), assuring precision across the operating temperature range. Compliance with Accuracy Class 1 and the ANSI C39.1 specification guarantees repeatable angular positioning over its 240° scale. The integrated scale length of 6.9″ (179 mm) provides high-resolution feedback, while mounting studs of 1/4″ UNF and terminal studs of 10/32 UNF facilitate secure mechanical and electrical connections. These features combine for stable, low-noise operation and simplified installation.
Reliability is enhanced by dual feedback devices: a tachofeedback element and an incremental encoder, delivering real-time speed and position data for closed-loop control. The centering diameter of 095 ensures consistent alignment and easy integration into modular assemblies. Designed for industrial automation, the motor’s robust sealing and harmonic stability support prolonged duty cycles with minimal maintenance. It is ideally suited for precision motion control in packaging machinery, assembly lines, robotic systems, and other applications where high responsiveness and durability are required.
