The Bosch Rexroth Indramat MAC112C-0-ED-4-C/130-A-1/WI1520LX/S05 is a high-performance AC servomotor in the MAC AC Servo Motors series by Bosch Rexroth Indramat. This compact unit features a part_number of MAC112C-0-ED-4-C/130-A-1/WI1520LX/S05 and belongs to the robust series designed for demanding automation tasks. With a Motor Size of 112 and a Motor Length designation of C, it delivers an exceptional torque-inertia ratio that optimizes dynamic response. The servomotor’s Winding Type is ED, ensuring reliable thermal performance and continuous operation under cyclic loads. Its construction complies with Product Group MAC standards, guaranteeing compatibility across a wide range of drive controllers.
In terms of technical capabilities, the servomotor offers a Type of Cooling through natural convection, promoting efficient heat dissipation without the need for additional hardware. A Blocking Brake rated Yes provides secure holding when power is removed, with a Holding Torque of Blocking Brake of 40 Nm to maintain position under load. The integrated Encoder system is Incremental, paired with a Tacho Type of Standard to enable precise speed and position feedback. The enclosed Housing Coat uses a Black Prime Coat finish for corrosion resistance and easy repainting within a maximum thickness of 40 μm. These specifications together support high acceleration, deceleration, and rapid reversals, making it ideal for servo-driven axes and indexing tables.
Operationally, this brushless design features lifetime lubricated bearings and permanent magnets on the rotor for maintenance-free reliability. The unit exhibits high overload capacity, delivering peak torque over a wide speed range while supporting continuous start-stop cycles at high repetition rates. Protection up to IP65 ensures dust-tight performance and resistance to water jets, with all power, tacho, and encoder cables meeting IP65 demands. Weighing just 1.1 kg, the motor’s high power-to-weight ratio supports compact machine layouts without sacrificing force output.
Integration of the MAC112C model is straightforward, thanks to its pilot diameter of 130 mm and a nominal winding speed of 3000 rpm. The standard holding brake operates at a nominal voltage of 14 V and nominal current of 0.75 A, facilitating safe stops and emergency holds. With its versatile interface and compliance with industry mounting norms, this servomotor is ready for employment in robotics, packaging machinery, CNC axes, and other precision motion control applications where space constraints and reliability are critical.
