MCS030-3S-0180-NNNN
The Bosch Rexroth Indramat MCS030-3S-0180-NNNN is part of the prestigious MCS Linear Motors series, designed for precision linear actuation in automated systems. This MCS Ironless linear motor secondary part features a Frame Size of 030 and a Secondary Part Length of 180 mm, making it ideally suited for applications requiring compact, high-accuracy motion. Its primary function is to convert electromagnetic force into linear motion, enabling smooth, repeatable positioning in pick-and-place systems, semiconductor handling, and assembly automation.
Incorporating a robust Fastening Method using three Screws per mounting point and a standard Mounting Style, the MCS030-3S-0180-NNNN ensures secure installation and reliable mechanical stability. The unit’s ironless design eliminates cogging effects, resulting in virtually frictionless operation and minimal heat generation. With Other Design Features explicitly listed as None, the motor maintains a streamlined form factor that simplifies integration. The iron yoke is configured in a U-shaped profile and must be mounted in an S shape configuration to achieve optimum electromagnetic coupling and force density, setting this motor apart from conventional linear actuators.
The MCS030-3S-0180-NNNN offers proven durability and efficiency, relying on its ironless secondary part to reduce wear and extend operational life. The motor’s compatibility with standard machine frames and Bosch Rexroth mounting accessories ensures seamless integration into existing automation platforms. It operates reliably within rated environmental conditions, with no additional protective coatings required thanks to its simple design. While no formal ISO certifications are specified, the high-quality manufacturing standards of Bosch Rexroth Indramat guarantee consistent performance. In industrial applications, this motor delivers enhanced throughput, precise positional control, and reduced maintenance costs, making it an excellent choice for demanding linear motion tasks.
