C image of MHD093B-035-PG1-BA | Main (Front Left)

MHD093B-035-PG1-BA

by Bosch Rexroth Indramat
$6,006.30 - $12,936.00
$6,006.30
$6,006.30 - $12,936.00
$6,006.30

In Stock, Ships 1 - 3 Days

The Bosch Rexroth Indramat MHD093B-035-PG1-BA is a powerful synchronous motor designed for automation systems. With a maintenance-free operation due to its brushless design and lubricated bearings, it offers an integrated multiturn absolute encoder for digital servo feedback. It's easy to install in any position because of its DIN 42948 compliant flange and is built with Class F insulation, adhering to DIN VDE 0530 Part 1 standards. Weighing 19kg, it has a heavy-duty bearing for high radial loads and must be used in original condition without hardware modifications. Its flange measures between 140mm and 150mm with a centering diameter of 130mm. Complete with a plain shaft featuring an end-sided centring hole with DS thread and a B-side power connector output, the motor yields maximum speed of 4,500min-1 and a winding inductivity of 10.7mH.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Bosch Rexroth Indramat

Product Type

Synchronous Motor

Model

MHD093B-035-PG1-BA

Holding Brake

22Nm

Design

Brushless

Bearing Lubrication

Grease

Installation

Flange as per DIN 42948 specifications

Motor Positioning

Any position

Encoder

Integrated multiturn absolute encoder

Feedback Type

Digital Servo Feedback

Insulation

Class F as per DIN VDE 0530 Part 1

Weight

19kg

Bearing

Designed for high radial loads

Usage

Only in original state without modifications

Operations

Main Drive Motor; needs additional actuators and sensors

Safety Instructions

As per Documentation

Flange Size

140mm or 150mm

Centering Diameter

130mm

Shaft

Plain shaft with end-sided centering hole with DS thread

Power Connector Output

Towards the B side of the motor

Winding Inductivity

10.7mH

Maximum Speed

4,500min-1

Transportation

Freight carriers
