MHD095B-035
The MHD095B-035 is a compact rotary actuator built by Bosch Rexroth Indramat as part of the MHD Synchronous Motors series. It operates as a permanent-magnet servo element that receives sinusoidal drive currents and delivers commanded shaft motion for positioning, conveying, or cyclic processing duties inside automated machinery. By integrating feedback transducers with a low-cogging magnetic circuit, the unit allows the associated drive controller to hold setpoints precisely across variable loads and duty cycles common in packaging lines, pick-and-place arms, and indexing systems. This operating style supports smooth motion, stable speed regulation, and accurate stopping behavior during repeated machine cycles.
This motor can apply a continuous standstill torque of 17.5 Nm, meaning that it can hold that torque continuously without exceeding the rated winding temperature when the shaft is locked. The motor has a centering diameter of 130 mm, which aligns the stator housing concentrically with the machine frame and helps reduce radial runout at the mounting face. It also has a flange size of 140 / 150 mm, so the housing fits standardized mounting patterns used on compatible equipment. These dimensions help the motor seat accurately on the machine while keeping the mechanical interface consistent across similar installations.
The motor frame designation 095 identifies the stator outer diameter used for this model. Length code B indicates the second shortest rotor stack in the family, which gives a balance between compact size, rotor inertia, and continuous output capability. Electrical behavior is set by winding code 035, which matches the motor to suitable drive voltage and current conditions for normal operation. Classified as a servo motor, the unit is intended for feedback-controlled motion where fast acceleration, accurate velocity tracking, and stable position holding are required. This makes it suitable for automated systems that need repeatable axis movement under changing load conditions.
