MHD112D-027-NG3-BN

Original price $17,214.66 - Original price $17,214.66
Original price
$17,214.66
$17,214.66 - $17,214.66
Current price $17,214.66
In Stock, Ships Today
Request a quote
Bosch Rexroth's MHD112D-027-NG3-BN is a highly efficient, high-torque servomotor from the MHD Synchronous Servo Motor series. Renowned for their high torque densities, these motors are specifically engineered to produce optimum torque throughout their speed range. The MHD112D-027-NG3-BN motor is available in both naturally cooled 60K and 100K versions, as well as a surface cooled variant fortified with a forced convection air blower. All versions maintain an operation speed of 2,000 RPM and can reach speeds up to 3,000 RPM. Considered one of the safest motors on the market, the product adheres to IP65 protection standards and weighs 56 kg. Additional features include a digital servo feedback mechanism enabled via an in-built relative positioning encoder and a 70Nm holding brake for de-energizing shaft stability.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product: MHD112D-027-NG3-BN
  • Product Type: Synchronous Servo Motor
  • Torque Densities: 60K version: 27.3Nm, 100K version: 41.5Nm, Surface cooled variant: 59.2Nm
  • Rated performance: 60K version: 6.9kW, 100K version: 11.3kW, Surface cooled variant: 15.2kW
  • Rated speed: 2,000 RPM
  • Max speed: 3,000 RPM
  • Protection degree: IP65
  • Mass: 56 kg
  • Feedback mechanism: Digital servo
  • Reltive positioning encoder: Installed
  • Holding Brake: 70Nm
  • Application: Motion control
