MHD115A-024-NP0-AN
The MHD115A-024-NP0-AN, developed by Bosch Rexroth Indramat, is a highly reliable and maintenance-free servo motor which is part of the MHD family. Special magnets in its assembly permit a design with low inertial mass, enabling high overload capabilities and wide-ranging usable peak torque. The fully sealed housing, rated IP65, allows the motor to function optimally even under adverse conditions. It can be cooled via natural convection or liquid cooling, the latter offering superior heat dissipation suitable for high-load applications. When liquid cooled, the motor features various electrical parameters including 60.8 Nm continuous stall torque, 41.2 Amps stall current and a rated speed of 2000 RPM. Recommended operating environment ranges from 0 to 40 degrees Celsius and up to 1000 meters altitude. The servo motor, which incorporates a digital servo feedback mechanism and a key-per-DIN 6885-1 main shaft, comes without a holding brake. Note that the MHD115A-024-NP0-AN should be operated by trained personnel and its usage outside of specified conditions is discouraged.
