MKD041B-143-GG0-KN
The MKD041B-143-GG0-KN AC Servo Motor, produced by Rexroth Indramat, is designed to generate kinetic energy for industrial applications, excelling in environments that may be challenging for other servo motors. Key features include advanced stator windings for enhanced heat dissipation, lubricated grease bearings for reduced frictional heat at the motor's shaft, a brushless design, and high durability. The servo motor comes with a specialized flange for easy installation.
When operating under a 60K housing temperature, the MKD041B-143-GG0-KN servo motor has a rated current of 1.6A, a rated speed of 3,000min-1, and generates a power output of 0.32kW, whereas at 100K winding overtemperature, the motor has a rated current of 2.8A, rated speed of 3,000min-1, and produces a power output of 0.54kW. At maximum speed (7,500min-1), it draws 34A. Follow all instructions in the drive documentation to ensure optimal, safe performance. Only properly-trained operators should use this servo motor, and all connected accessories must meet specified requirements. Servo Supplier ships this unit globally with a one-year warranty.
