C image of MKD090B-035-KG1-KN | Main (Front Left)

MKD090B-035-KG1-KN

by Bosch Rexroth Indramat
$7,161.35 - $15,081.60
$15,081.60
$7,161.35 - $15,081.60
$15,081.60

In Stock, Ships 1 - 3 Days

The MKD090B-035-KG1-KN synchronous motors by Bosch Rexroth Indramat offers a superior solution for the mechanical, electrical, and engineering markets thanks to its leading technology. With an optimised electromagnetic design, this reduces torque ripple, ensuring increased product quality through constant path velocity. Key specifications include a maximum setup height of 1000m above sea level and a weight of 14kg. Boasting a rated speed of 3000 min-1 and a maximum of 5000 min-1, the motor's winding resistance and inductance aid in minimising internal losses. The motor operates between -20 to +80 degrees Celsius and can safely be stored within this temperature range. A F class insulation according to DIN VDE 0530 part 1 is implemented to ensure safety, while the motor's durable black housing aids longevity. The rated frequency and peak current for the motor under any cooling system is 2000 Hz and 49.5 A respectively, and it delivers a theoretical maximum torque of 43.4 Nm. With a voltage constant of 111V/1000 min-1 and a torque constant of 1.22 Nm/A, the motor's operational data may need to be adjusted if these specified limits are exceeded.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

2 - 4 Days
Handling Time

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Bosch Rexroth Indramat

Product Type

Synchronous Motors

Model

MKD090B-035-KG1-KN

Maximum Setup Height

1000m above NN

Minimum Strand Cross-Section

1mm2

Motor Mass

14.0kg

Rated Speed

3000 min-1

Maximum Speed

5000 min-1

Optimal Winding Resistance

1.88 Ω

Winding Inductance

15.5 mH

Pole Pairs

4

Storage Temperature

-20 to +80 degrees Celsius

Permissible Ambient Temperature

0 to 40 degrees Celsius

Insulation Class

F

Housing Coat

Prime Black a/w RAL 9005

Rated Frequency (Any Cooling System)

2000 Hz

Peak Current (Any Cooling System)

49.5 A

Theoretical Maximum Torque (Any Cooling Method)

43.4 Nm

Voltage Constant

111V/1000 min-1

Torque Constant

1.22 Nm/A
