MKD093B-035-KG1-RF
The product at hand is the Bosch Rexroth MKD093B-035-KG1-RF servomotor from the MKD series, renown for applications in industrial automation, machine tools and food industry amongst others. This synchronous motor is highly reliable and offers overload protection, in addition to a maximum torque usable across an extensive speed range. As a three-phase, permanent magnet motor, it has a speed capacity of 4500 RPM, a 22 Nm rated holding brake, and weighs 20.1 kg. With an IP 65 protection rating, the motor housing ensures safety from environmental factors. The motor shaft comes with a sealing ring and supports feedback through a built-in resolver feedback with integrated multiturn absolute encoder. The performance varies in convection cooled mode (a torque of 17.5 Nm and 12.8 Amps current) and liquid-cooled mode (33.3 Nm torque and 24.3 Amps current). Besides operating within an optimal installation altitude of 1000 meters and a temperature range of 0-40°C, it also has a winding code of 035, an insulation class of F and is painted in prime black. The manufacturer assumes no liability for misuse. The product can be shipped globally, with a one-year warranty from Servo Supplier.
