MS2N03-D0BYN-CMSH1-NNNNN-NN
The Bosch Rexroth Indramat MS2N03-D0BYN-CMSH1-NNNNN-NN servo motor represents a high-performance member of the MS2N Synchronous Servo Motors series, offering precise motion control for demanding industrial applications. Engineered for rapid response and repeatable accuracy, this unit delivers a Nominal Speed of 5700 RPM while maintaining a Rotor Inertia of 0.44 x 10^-4 kgm^2 for optimal dynamic performance. Its compact design incorporates a Multiturn encoder and an integrated Holding Brake included, ensuring secure positioning during power loss or emergency stops. The motor’s Connection Type M23 Single-Cable interface simplifies installation and wiring, reducing system complexity. Additionally, the smooth no-shaft-seal shaft design extends service life by minimizing friction and contamination ingress.
The motor’s technical specifications emphasize reliability and maintainability. It employs Bearing Type Standard Type bearings, which require lubrication at Bearing Lubrication Interval Every 15,000 cycles and bearer replacement at Bearing Replacement Interval Every 20,000 cycles to sustain performance over extended duty cycles. The Insulation Class F (up to 170 °C) rating ensures thermal resilience under overload and heat-generating processes. Protection is afforded by an Protection Rating IP 65, guarding internal components against dust and water jets. Mounting is standardized via a Mounting Type Flange interface, facilitating straightforward integration into existing machinery. The motor is capable of achieving a Maximum Speed of 9000 RPM when fitted with reinforced rolling-element bearings, meeting the demands of high-speed automation tasks.
Operationally, this servo motor achieves rapid acceleration and deceleration profiles owing to its low inertia design, which directly contributes to high throughput in time-critical operations. Vibration is mitigated through a Vibration Reduction Reinforced Body, reducing mechanical resonance and wear on chassis components. The multiturn encoder provides precise feedback across multiple revolutions, eliminating the need for homing sequences after power cycles. Thermal management benefits from the class F insulation system, which permits continuous operation in environments with elevated ambient temperatures. Equipment uptime is further enhanced by the integrated holding brake, which engages automatically upon loss of drive pressure or power, meeting safety requirements for vertical and horizontal axes alike.
System integration is facilitated by compatibility with standard drive controllers and servo amplifiers from Bosch Rexroth. The robust IP65 enclosure and class F insulation make this motor ideal for use in sectors such as packaging machinery, automated assembly lines, food and beverage processing, and textile winding systems. The M23 single-cable connection and flange mounting interface minimize installation time and spare-part inventories. Overall, the MS2N03-D0BYN-CMSH1-NNNNN-NN provides a balanced combination of precision, speed, and ruggedness, targeting applications where high-speed operation and reliable environmental protection are critical.
