series image of MSK030C-0900-NN-S3-UP0-NNNN

MSK030C-0900-NN-S3-UP0-NNNN

by Bosch Rexroth Indramat
$7,764.84 - $7,764.84
$7,764.84
$7,764.84 - $7,764.84
$7,764.84
In Stock, Ships Today
The Bosch Rexroth Indramat MSK030C-0900-NN-S3-UP0-NNNN is a bespoke servomotor from the MSK series. It uses a single-turn Hiperface encoder with 16 signal periods. The MSK030C-0900-NN-S3-UP0-NNNN hosts a plain shaft and shaft sealing ring and cools naturally. With a 30 overall motor frame size and a C overall motor frame length, this motor is devoid of a holding brake. The MSK030C-0900-NN-S3-UP0-NNNN operates at 0-40 degrees C, offers protection degree IP 65 per DIN EN 60034-1, and insulation class 155. With a 15 minute thermal time constant, this compact and high-density torque motor provides precision and dynamic performance and is widely applicable in standard servo motor configurations and diverse areas such as robotics, food processing, and printing. Weighing 1.9 kg, with a 0.00003 kgm2 inertia and 6.8 A maximum current, it generates up to 4 Nm torque under full load. It can be paired with IndraDrive control units for customised drive solutions.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product Line: MSK Servomotors
  • Model: MSK030C-0900-NN-S3-UP0-NNNN
  • Encoder: Single-turn Hiperface with 16 signal periods
  • Shaft: Plain with seal ring
  • Cooling System: Natural Convection
  • Motor Frame Size: 30
  • Motor Frame Length: C
  • Holding Brake: None
  • Operating Temperature: 0 to 40 degrees C
  • Protection Degree: DIN EN 60034-1 IP 65
  • Insulation Class: 155
  • Thermal Time Constant: 15 minutes
  • Uses: Robotics, machine tools, food processing machines, printing machines
  • Weight: 1.9 kg
  • Moment of Inertia: 0.00003 kgm2
  • Maximum Current: 6.8 A
  • Torque Capacity: 4 Nm
  • Continuous Current at 60K Standstill: 1.5 A
  • Continuous Current at 100K Standstill: 1.7 A
