MSK060B-0300-NN-M1-UP0-NNNN

Original price $3,362.63 - Original price $3,362.63
Original price
$3,362.63
$3,362.63 - $3,362.63
Current price $3,362.63
Available, Shipping Varies
Request a quote
The MSK060B-0300-NN-M1-UP0-NNNN is a servomotor from Bosch Rexroth Indramat's MSK series. Designed for versatility, it's adaptable for various industrial applications, from robotics to food processing. This specific model offers a torque-density up to 15Nm for a weight of 5.7kg, excellent for tasks requiring high torque density. Measuring 231mm in length with a 116mm flange size and a centering diameter of 95mm, it employs a standard MSK motor design. The shaft is built with a keyway and sealing rings for added load fastening security. Though it can operate up to 145C, its optimal ambient temperature range is 0-40C to maintain effective natural convection cooling. With a continuous torque at standstill of 5Nm and a maximum speed of 4800min-1, it is fitted with an optical encoder, providing precise positional accuracy. The motor further features top-mounted, rotatable connectors for the power cable and encoder output, offering installation flexibility.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product Line: MSK Series
  • Model: MSK060B-0300-NN-M1-UP0-NNNN
  • Applications: Industrial robotics, food processing automation
  • Torque-Density: Up to 15Nm
  • Weight: 5.7kg
  • Length: 231mm
  • Flange Size: 116mm
  • Centering Diameter: 95mm
  • Motor Design: Standard MSK
  • Shaft Design: DIN 6885-1 Key and Keyway, Sealing Rings
  • Holding Brake: Absent
  • Operational Temperature Range: 0 – 40℃
  • Maximum Operational Temperature: 145℃
  • Thermal Class: F (EN 60034-1)
  • Protection Level: IP65 (EN 60034-5)
  • Continuous Torque at Standstill: 5Nm
  • Maximum Speed: 4800min-1
  • Encoder Type: Optical, Multiturn-Absolute Hiperface, 128 Signal Periods
  • Electrical Connector: Top-mounted, 2400 Rotatable
  • Cooling Type: Natural Convection
