MSK100B-0300-NN-M1-BG1-NNNN

Original price $8,048.25 - Original price $8,048.25
Original price
$8,048.25
$8,048.25 - $8,048.25
Current price $8,048.25
In Stock, Ships 3 - 5 Days
Request a quote
The MSK100B-0300-NN-M1-BG1-NNNN, a high-performance servo motor from renowned manufacturer Bosch Rexroth Indramat, stands out for its versatility, precision, and power. Its innovative design suits a wide range of applications, from main and servo drives to metal-forming machines and linear drives. With high torque density, dynamic properties, and advanced integrated optical encoder systems, it defines precision. Besides, it allows custom configuration for compatibility with multiple motor types. Despite its compact size, it delivers remarkable power, categorizing it as a best-in-class high-output motor. Significant features include a wind code of 400, motor size 100, a cooling mode based on natural convection, and an optical encoder with Hiperface and 128 increments. It also incorporates a DIN 6885-1 compliant keyway shaft and a sealing ring for optimal shaft bearing lubrication and protection from splashing fluids. It delivers a maximum torque of 102Nm, a maximum current of 106.7A, and runs quietly at high speeds.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product type: Servo Motor
  • Model: MSK100B-0300-NN-M1-BG1-NNNN
  • Application: Main and servo drive, kit motor, linear drive
  • Technology: Latest motor technology, integrated optical encoder systems
  • Configuration: Configurable, compatible with other motors
  • Power Output: High relative to weight and size
  • Motor size: 100
  • Winding code: 0300
  • Cooling mode: Natural convection
  • Encoder: Optical, multiturn-absolute Hiperface, 128 increments
  • Connector: A-side
  • Shaft: Keyway per DIN 6885-1 with a sealing ring
  • Brake: No holding brake
  • Design: Standard, compatible with other designs
  • Maximum torque: 102.0Nm
  • Maximum current: 106.7A
  • Constant torque at a standstill: 28Nm
  • Noise levels: 75dB
