S image of MTC1506B1-R2C1

MTC1506B1-R2C1

by Kollmorgen
$4,065.75 - $5,562.05
$4,065.75
$4,065.75 - $5,562.05
$4,065.75

In Stock, Ships Fast

The MTC1506B1-R2C1 from Kollmorgen's Goldline 150 XT series is a high-performing brushless servo motor that ensures efficient operation with Servostar CD controllers at 115 Volts AC and 230 Volts AC. It's NEMA 23 mountable, equipped with a 24 Volts DC brake and resolver-based feedback system. The motor offers excellent torque/inertia with a maximum operating speed of 6000 RPM, and can deliver continuous stall torque up to 1.10 lb-ft at 25 ºC. The motor is tightly sealed with an IP65-rated cover, protecting it from any potential damage and oil leakage. The compact motor dimensions are 115.9mm height, 60mm width, and 205mm length, with a weight of 1.9 kg without the brake. For safe and effective installation and operations, a certified technical professional equipped with the necessary training should follow the instructions provided in the product manual.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Kollmorgen

Product Line

Goldline 150 XT

Motor Type

Brushless Servo Motor

Drive Compatibility

Servostar CD 115/230 Volts AC

Features

24 Volts DC Brake, Resolver-based feedback, NEMA 23 mounting, 90-degree rotatable connection receptacles, Standard shaft seal

Optional Features

IP67 Sealing, Holding Brake, Resolver Feedback, Mating Connectors

Environmental Protection Rating

IP65

Frame Size

60 millimeters

Magnet Stack Length

6

Dimensions

115.9mm Height, 60mm Width, 205mm Length

Weight

1.9 kilograms (without brake), 3.3 kilograms (with brake)

Operating Speed

6000 RPM

Stall Torque

1.02 lb-ft at 40°C, 1.10 lb-ft at 25°C

Maximum Motor Torque

3.44 lb-ft

Motor Current

5.9 Amp Continuous, 22.7 Amp Peak

Installation Requirements

Qualified Technical Personnel, Adherence to Product Manual Instructions
