S image of MTC304B1-R1C1

MTC304B1-R1C1

by Kollmorgen
$4,488.75 - $4,488.75
$4,488.75
$4,488.75 - $4,488.75
$4,488.75

In Stock, Ships 1 - 3 Days

The Kollmorgen MTC304B1-R1C1 is a brushless motor of the Goldline XT series, offering standard options like IP65/IP67 sealing, four stack lengths, an electromagnetic brake, NEMA 34/100 mounting and either resolver or encoder feedback. With a 90mm frame length, the MTC304B1-R1C1 provides 1.85 horsepower or 1.38 kilowatts, with a speed of 6000 RPM and peak torque of 7.41 Nm. Accommodating a steady-state line current of 5.53 Amps, peaking at 20.9 Amps, the motor also displays a DC resistance at 25 degrees Celsius of 1.70 Ohms. The MTC304B1-R1C1 is supplied with a multitude of features, including a motor shaft seal to prevent oil leakage and dust ingress, NEMA 100 mounting, and a brake rated for 24 Volts DC, creating a robust and reliable product designed to meet a variety of industrial needs.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Kollmorgen

Product Code

MTC304B1-R1C1

Motor Type

Brushless

Product Series

Goldline XT

Sealing Options

IP65/IP67

Stack Lengths

Four

Special Features

Integral failsafe electromagnetic brake, NEMA 34/100 mounting, resolver or encoder feedback

Certifications

CE, UL

Compatibility

Servostar CD digital servo amplifiers

Frame Length

90 millimeters

Magnet Stack Length

4

Output Power

1.85 Horsepower, 1.38 kilowatts

Motor Speed

6000 RPM

Motor Continuous Torque (stall) at 40 degrees Celsius

2.58 Nm

Motor Continuous Torque (stall) at 25 degrees Celsius

2.73 Nm

Peak Motor Torque

7.41 Nm

Steady-State Line Current

5.53 Amps

Peak Line Current

20.9 Amps

Torque Sensitivity (stall)

0.473 Nm/Amp

Line-to-Line Back EMF

28.6 VRMS/kRPM

DC Resistance at 25 degrees Celsius

1.70 Ohms

Rotor Inertia

0.000808 kg m2

Static Friction

0.035 Nm

Weight with Brake

4.3 kilograms

Weight without Brake

3.3 kilograms

Additional Features

Holding brake rated for 24 Volts DC, resolver for feedback, NEMA 100 mounting option, 90-degree swivel receptacles for power/feedback connection and a seal on the motor shaft.
