S image of MX2000-2

MX2000-2

by Kollmorgen
$2,243.75 - $2,243.75
$2,243.75
$2,243.75 - $2,243.75
$2,243.75

In Stock, Ships 1 - 3 Days

The MX2000-2, a programmable motion controller manufactured by Kollmorgen, operates on DSP for enhanced performance and includes a multitude of inputs and outputs. Designed to function either independently or in conjunction with operator interfaces, it includes a standard axis card for direction and pulse signals compatible with most stepper drives. With a maximum pulse rate of 1.99 MHz, it can manage drives up to 50,000 pulses per revolution. The controller also features analog outputs that serve as a torque command for a servo drive. Running on a 90 to 265 VAC at 50/60 Hz input frequency, it also incorporates inputs from two incremental encoders (2 MHz max count rate), 5VDC power for encoder energizing, and a built-in 24 VDC supply for I/O. Mathematical and logical operations, various motion profiles, and error warning displays further amplify its convenience and multifunctionality.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Kollmorgen

Product Model

MX2000-2

Type

Programmable motion controller

Based on

DSP

Communication Compatibility

Intelligent or dumb operator interfaces

Functional Without Operator Interface

Yes

Included Axis card

Standard pulse and direction signals

Pulse Rate Compatibility

Up to 50,000 pulses per revolution

Maximum Pulse Rate

1.99 MHz

Additional Outputs

Analog outputs for torque command of servo drive

Encoder Input

Inputs from two incremental encoders

Maximum Count Rate

2 MHz

Built-In Power

5VDC for encoders, 24VDC for I/O

AC Line Filter

Built-in

Power Supply

90 to 265 VAC, 50/60 Hz input frequency

Coding

BASIC line coding

Math Capability

Full, including square root, log, and trigonometric functions

Boolean logic functions

Supported

Complex Motions

Supported, including arc, line, and path

Velocity Change

Allowed during motion

Trigger Motions

Supported, including move-home

Error Handling

Displays warning messages
