P20B10150HXS0E

The Sanyo Denki P20B10150HXS0E is a high-efficiency planetary gear motor from the renowned P2 Super BL Servo Motors series, designed to meet the demanding requirements of modern industrial automation. This flange-mounted unit features Brushless DC technology and delivers a rated power of 150W at a rated voltage of 24V DC, ensuring smooth, responsive control. The integrated planetary gear motor design incorporates a gear ratio of 10:1 and a compact shaft diameter of 8 mm to maximize torque density while minimizing footprint. With an inertial level classified as Low inertial, the P20B10150HXS0E achieves rapid acceleration and deceleration profiles. Its robust construction includes a durable Black RAL 9005 coating for enhanced wear resistance and a total weight of only 1.8 kg, optimizing the power-to-weight ratio for space-constrained installations.

Performance characteristics of the P20B10150HXS0E are engineered for precision and longevity. The motor produces a rated torque of 0.48 Nm at a rated speed of 3000 rpm, balancing high speed operation with steady-state stability. An optional encoder interface allows seamless integration with advanced motion controllers, while the flange mount configuration simplifies mechanical coupling. The low inertial rotor enables high-frequency positioning cycles without compromising accuracy, and the planetary gear stage provides consistent torque multiplication under varying loads. Its protection class IP54 ensures reliable performance in dusty environments, while the specified operating temperature range from -10°C to +40°C maintains consistent output across typical factory conditions. The unit’s efficient design and optimized thermal characteristics reduce heat buildup, extending service life even under continuous duty.

Built for integration into automated systems, the P20B10150HXS0E is compatible with Sanyo Denki’s PY series drive controllers, forming a cohesive motion solution for precision tasks. The flange mount design and standardized interface facilitate straightforward installation in both horizontal and vertical orientations, though use of a rigid coupling and cable trap is recommended to prevent misalignment and ingress of contaminants. Routine inspection of the optional encoder and adherence to IEC standard maintenance schedules preserve peak performance and accuracy. The robust planetary gear train and low-inertia rotor combine to deliver smooth, repeatable motion in applications such as pick-and-place modules, assembly robots, and conveyor indexing systems. The compact, lightweight form factor and high power density make this servo motor ideal for tight integration where reliability and precision are paramount.
